Powder Multilane Packing Machine
Technical details
Item | SF2.0S | SF3.0S | SF4.0S |
Track Number | 4-10 (Track) | 4-12 (Track) | 4-12 (Track) |
Filling Method | Auger filler by servo motor | ||
Capacity | 30-45 cut/min (According to the material condition) | ||
Film Width & Thickness | 520 mm, 0.06-0.1 mm | 720 mm, 0.06-0.1 mm | 820 mm, 0.06-0.1 mm |
Sachet Size | L: 45-160 mm / W: 17-80 mm (Customized bag length) | ||
Sealing Type | Back sealing / Stick bag | ||
Cutting Type | Flatten cutting / Zig zag cutting / Round cutting | ||
Air Consumption & Voltage | 0.8 MPa0.8 m³ / 4.5 kW | 0.8 MPa0.8 m³ / 5.5 kW | 0.8 MPa0.8 m³ / 6.5 kW |
Power | AC380V Three phase, AC220V Single phase, 50-60Hz | ||
Dimension & Total Weight | L1400×W2000×H2800 mm1100 kg | L1500×W2000×H2800 mm1200 kg | L1600×W2100×H2800 mm1300 kg |
APPLICATIONS
This multi-lane powder stick pack packaging machine is designed for automatic, high-speed packaging of a wide range of fine, free-flowing, and light dusty powder materials.
Typical applications include food powders, beverage powders, coffee creamer, milk powder, seasoning and spice powders, protein and nutritional powders, pharmaceutical powders, chemical additives, and daily-use powder products.
The machine supports 4–10 lane back-seal stick pack/backing sealing or four side seal sachets, delivering high production efficiency, stable filling accuracy, and consistent sealing performance. It is widely applied in food processing plants, pharmaceutical factories, chemical manufacturing facilities, and industrial powder packaging lines that require continuous, large-scale, and reliable automated production.
To help us recommend the most suitable multi-lane high-speed powder packaging solution, please kindly provide the following information when sending your inquiry:
Product type and powder characteristics (flowability, dust level, hygroscopicity)
Sachet or stick pack dimensions (length and width)
Filling weight per sachet
Packaging style (stick pack, pillow sachet, back seal, etc.)
Required production speed and output capacity
PACKAGING
Applicable Packaging Film: BOPP/Polyethylene, Aluminium/Polyethylene, Polyester/Aluminizing/Polyethylene, Nylon/CPP, Paper/Polyethylene, etc.
FUNCTIONAL FEATURES
1.The equipment frame is made of 304 stainless steel, in line with food QS and pharmaceutical GMP hygiene standards;
2.Equipment with safety protection, in line with enterprise safety management requirements;
3.Imported-brand electrical components; Siemens PLC + touch screen control, high reliability and intelligence, high speed and high efficiency;
4.Independent temperature control system with accurate control; sealing is beautiful and smooth;
5.Film pulling system and color mark control can be adjusted via touch screen; easy deviation correction and incision deviation correction; recipes can be stored for quick product changeover;
6.4–12 lanes packing according to bag width; can connect with dosing line and automatic cartoning machine to achieve packing & cartoning automation production line.
