Multi-lane Packaging Machine

4–10 Lane Ice Pop Packaging Machine for Multi-Flavor Ice Pops and Popsicles with Automatic Liquid Filling and Sealing System

Technical details

SP-720-6 Lane Multi-lane Packaging Machine Specifications

Machine Model
SP-720-6 Lane
Frame Material
304 Stainless Steel
Control System
Siemens System
Measuring Method
Liquid pump
Packaging Material
Ice pop liquid (3 flavors)
Product Spec
40g
Speed
20–25 packs/min/lane                STABLE
Pass Rate
99.7% (Reject ≤ 3/1000)
Bag Size
W: 33.3mm; L: 250mm
Thickness
6 silk (60 microns)
Film Width
6 lanes (400mm), 2 rolls
Film Material
Composite film
Sealing Size
V: 7mm; H: 6mm
Opening Style
Straight notch (I-shaped)
Sealing Pattern
Reticulated / Checked
Voltage
380V, 50Hz, 3-Phase

* All technical data is based on standard factory testing conditions.

Share:

APPLICATIONS

This multilane ice pop packaging machine is designed for automatic filling and sealing of various liquid products used in frozen treats and beverage applications. It is widely used for ice pops, popsicles, flavored water, fruit juice, syrup-based drinks, milk-based beverages, and other free-flowing liquids.

The system supports multi-flavor production by enabling different liquid feeds across multiple lanes, allowing manufacturers to produce assorted ice pops in a single production run. It is suitable for both low-viscosity liquids such as juice and water-based drinks, as well as slightly viscous liquids like sugar syrup, flavored gel drinks, and dairy-based mixtures.

With high-speed multilane operation, stable sealing performance, and consistent filling accuracy, the machine is ideal for beverage factories, frozen dessert producers, and seasonal ice pop production lines requiring efficient and continuous output.


Kindly Reminder

Please provide the following information when sending us your inquiry. Based on your details, we will recommend the most suitable ice pop or liquid packaging solution for your reference.

1. Product type and flavor(s)

2. Pouch dimensions (length and width)

3. Liquid filling volume per pouch

4. Bag style (back seal, stick, or other)

5.Required production capacity (units per hour)

PACKAGING

 Applicable Packaging Film: BOPP/Polyethylene, Aluminium/Polyethylene, Polyester/Aluminizing/Polyethylene, Nylon/CPP, Paper/Polyethylene, etc.

FUNCTIONAL FEATURES

  1. The equipment frame is made of 304 stainless steel, in line with food QS and pharmaceutical GMP hygiene standards

  2. The electrical components are imported famous brands, stable and efficient, with low failure rate;

  3. Equipped with safety protection, in line with enterprise safety management requirements;

  4. Independent temperature control system is adopted, and the temperature control is accurate; the sealing is beautiful and smooth;

  5. Siemens PLC control, touch screen control, automatic control capability of the whole machine, high reliability and intelligence, high speed and high efficiency;

  6. Independent servo motor metering, servo motor pull film, film pull system and eyemark system can be automatically adjusted through touch screen, automatic correction system of roll film system, automatic storage of multiple products formulas, replacement of products can be used at any time without adjustment, no adjustment is required.
