Technical details
| Parameter | SF2.0S | SF3.0S | SF4.0S |
| Track Number | 4–10 tracks | 4–12 tracks | 4–12 tracks |
| Filling Method | Peristaltic pump / Piston pump / Ceramic pump | ||
| Packaging Speed (Capacity) | 30–55 cuts/min (According to the material condition) | 30–45 cuts/min (According to the material condition) | 30–45 cuts/min (According to the material condition) |
| Film Width and Thickness | Max. 520 mm, 0.06–0.1 mm | Max. 720 mm, 0.06–0.1 mm | Max. 820 mm, 0.06–0.1 mm |
| Sachet Size | Length: 45–160 mm; Width: 17–80 mm (Customized bag length available) | ||
| Sealing Type | Back sealing / Stick bag | ||
| Cutting Type | Flat cutting / Zig-zag cutting / Round cutting | ||
| Air Consumption and Power | 0.8 MPa, 0.8 m³/min, 4.5 kW | 0.8 MPa, 0.8 m³/min, 5.5 kW | 0.8 MPa, 0.8 m³/min, 6.5 kW |
| Power Supply | AC 380V Three-phase / AC 220V Single-phase, 50–60 Hz | ||
| Dimension and Total Weight | L1400 × W2000 × H2400 mm, 1200 kg | L1500 × W2000 × H2500 mm, 1300 kg | L1600 × W2100 × H2600 mm, 1400 kg |
Description
Want this machine? Send us inquiry!
